Zebra ZD410 User Manual

97
USB Host Port and
Link-OS Usage Examples
This section has information on using the printer’s USB Host port along with Link-OS features and Apps
(applications).
USB Host
The USB host port allows you to connect USB devices — such as a keyboard, scanner, or USB Flash
(memory) drive — to the printer.
USB Host Port Uses
• Firmware updates
• File transfers and management
• A port for low power USB data entry devices (keyboards, scales, scanners, and other wedge
devices).
Important • The USB Flash drive must be formatted with the FAT file system. Filenames may be 1 to 16 alphanumeric
characters (A, a, B, b, C, c, ..., 0, 1, 2, 3, ...) only. Only use ASCII characters. Do not use Asian characters, Cyrillic
characters, or accented characters in file names. Some functions may not work properly if there are underscores in a
file name. Use periods instead.
USB Host Port

Zebra ZD410 Specifications

General

Wi-Fi	Yes
Ethernet LAN	No
Wi-Fi standards	Wi-Fi 5 (802.11ac)
Bluetooth version	4.1
USB 2.0 ports quantity	1
Connectivity technology	Wired & Wireless
Print technology	Direct thermal
Maximum resolution	300 x 300 DPI
Maximum print height	991 mm
Maximum printing width	56 mm
Flash memory	512 MB
Internal memory	256 MB
Built-in barcodes	1D, 2D
Page description languages	EPL, EPL2, XML, ZPL, ZPL II
Display	-
Product color	Gray
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Sustainability certificates	ENERGY STAR
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	5 - 41 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Core diameter	12.7 mm
Media thickness	0.08 - 0.305 mm
Maximum roll diameter	127 mm
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	220 mm
Width	115 mm
Height	151 mm
Weight	1000 g
