Zebra ZD410 User Manual

Setup for Windows OS
60
Configure Using the ZebraNet Bridge’s Connectivity Wizard
Note • The preferred tool for connecting and configuring Link-OS printers to cloud, WLAN, and LAN; is now Link-OS
Profile Manager. You can get Profile Manager and ZebraNet Bridge Enterprise (local and LAN configurations) utility is
available through http://www.zebra.com/software. ZebraNet Bridge Enterprise version 1.2.5 or later is required to
configure the printer correctly for use.
The Connectivity Wizard, which is part of this software, allows you to configure your printer easily for
wireless operation by writing the appropriate ZPL script for you. Use this utility when you are first installing
the wireless print server or after you set the network options back to factory defaults.
Note • You can only set up one print server at a time with the Connectivity Wizard. To configure multiple print servers
(wired and wireless), run the program once for each print server.
To use the Connectivity Wizard, complete these steps:
1. If it is not already installed, install ZebraNet Bridge Enterprise on your computer.
You can get the program from the Zebra Web site at http://www.zebra.com/software
.
2. Launch the ZebraNet Bridge Enterprise program.
If you are prompted for a serial number, you may click Cancel. You will still be able to use the
Connectivity Wizard.
3. From the Menu bar, select Tools > Connectivity Wizard. The Connectivity Wizard opens.
4. From the Choose Port list, select the port to which your printer is connected.
• If you will save the file without sending it to the printer, you may select any available port.
• If you select ‘File’, you will be asked to browse to the location of the file you want to save.
• If you select a serial port, the serial configuration information appears below the ‘Choose Port’ list. If
necessary, change the serial communication settings to match your printer’s settings.
Note • If a port is in use by another device, it will not be included in the drop-down list.

Zebra ZD410 Specifications

General

Wi-Fi	Yes
Ethernet LAN	No
Wi-Fi standards	Wi-Fi 5 (802.11ac)
Bluetooth version	4.1
USB 2.0 ports quantity	1
Connectivity technology	Wired & Wireless
Print technology	Direct thermal
Maximum resolution	300 x 300 DPI
Maximum print height	991 mm
Maximum printing width	56 mm
Flash memory	512 MB
Internal memory	256 MB
Built-in barcodes	1D, 2D
Page description languages	EPL, EPL2, XML, ZPL, ZPL II
Display	-
Product color	Gray
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Sustainability certificates	ENERGY STAR
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	5 - 41 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Core diameter	12.7 mm
Media thickness	0.08 - 0.305 mm
Maximum roll diameter	127 mm
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	220 mm
Width	115 mm
Height	151 mm
Weight	1000 g
