Zebra ZD410 User Manual

Tools
148
Advanced Mode
Advanced Mode is used to access several manual adjustment modes in the printer. Each manual
adjustment mode is described in detail in the following sections.
To activate Advanced Mode, complete these steps:
1. Ensure media is loaded and printer power is ON.
2. Press PAUSE for two seconds, all indicators will flash yellow.
3. The STATUS indicator ( ) will show solid yellow, indicating the currently selected mode is:
Manual Media Calibration.
4. Pressing FEED will sequentially cycle through all available modes.
5. Pressing PAUSE will activate the selected mode.
6. Pressing CANCEL will exit Advanced Mode.
Manual Media Calibration
While in Advanced Mode, pressing PAUSE while the Status indicator ( ) is illuminated yellow will start
Manual Media Calibration.
1. The MEDIA indicator ( ) will flash yellow then the Pause indicator ( ) will flash. Open the printer
and verify the media sensor is in the center position for label gap (transmissive) sensing. Remove 3
inches or 80mm of labels from the liner. Place the label-less area of the liner over the platen (drive)
roller with the leading edge of the first label under the media guides.
2. Close the printer and press PAUSE once. The MEDIA indicator ( ) will flash as the media liner is
measured. When complete, the Pause indicator ( ) will begin flashing.
3. Open the printer and reposition the media so that a label is located directly above the movable sensor.
Close the printer.
4. Press PAUSE once. The printer will FEED and measure several labels. If the printer is able to
determine the correct media type (gap, black mark or notch) and measure the media length, the printer
will return to the READY state.
This advanced mode is typically used to calibrate the printer to media that is not correctly recognized
during Smart Calibration. If your media uses black mark or notch sensing, ensure the media sensor is in to
the proper location to “see” the mark or notch. If your media is pre-printed, either on the front of the label or
on the back of the liner, position the sensor so that it is in a position with minimal printing. You may need to
perform Manual Media Calibration several times, moving the media sensor, until the printer completes the
calibration process and returns to the READY state.

Zebra ZD410 Specifications

General

Wi-Fi	Yes
Ethernet LAN	No
Wi-Fi standards	Wi-Fi 5 (802.11ac)
Bluetooth version	4.1
USB 2.0 ports quantity	1
Connectivity technology	Wired & Wireless
Print technology	Direct thermal
Maximum resolution	300 x 300 DPI
Maximum print height	991 mm
Maximum printing width	56 mm
Flash memory	512 MB
Internal memory	256 MB
Built-in barcodes	1D, 2D
Page description languages	EPL, EPL2, XML, ZPL, ZPL II
Display	-
Product color	Gray
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Sustainability certificates	ENERGY STAR
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	5 - 41 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Core diameter	12.7 mm
Media thickness	0.08 - 0.305 mm
Maximum roll diameter	127 mm
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	220 mm
Width	115 mm
Height	151 mm
Weight	1000 g
