Zebra ZD410 User Manual

Setup
41
Attaching Power
Caution • Never operate the printer and power supply in an area where they can get wet. Serious personal injury could
result!
Note • Set up your printer so that you can handle the power cord easily if needed. Some processes for setup or
troubleshooting issues may ask you to remove power. Separate the power cord from the power supply receptacle or
AC electrical outlet to make certain the printer cannot carry electrical current.
1. Plug the power supply into the printer’s DC power receptacle.
2. Insert the AC power cord into the power supply.
3. Plug the other end of the AC power cord into an appropriate AC electrical outlet. Note that AC outlet
end of the power cord’s plug type can vary by region.
4. The active power light will turn on green if power is on at the AC outlet.
Important • Ensure the appropriate power cord with a three (3) prong plug and an
IEC 60320-C13 connector are used at all times. These power cords must bear the relevant
certification mark of the country in which the product is being used.

Zebra ZD410 Specifications

General

Wi-Fi	Yes
Ethernet LAN	No
Wi-Fi standards	Wi-Fi 5 (802.11ac)
Bluetooth version	4.1
USB 2.0 ports quantity	1
Connectivity technology	Wired & Wireless
Print technology	Direct thermal
Maximum resolution	300 x 300 DPI
Maximum print height	991 mm
Maximum printing width	56 mm
Flash memory	512 MB
Internal memory	256 MB
Built-in barcodes	1D, 2D
Page description languages	EPL, EPL2, XML, ZPL, ZPL II
Display	-
Product color	Gray
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Sustainability certificates	ENERGY STAR
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	5 - 41 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Core diameter	12.7 mm
Media thickness	0.08 - 0.305 mm
Maximum roll diameter	127 mm
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	220 mm
Width	115 mm
Height	151 mm
Weight	1000 g
