Zebra ZD410 User Manual

Print Operations
94
Zebra
®
ZKDU — Printer Accessory
The Zebra® ZKDU (keyboard display unit) is a small terminal unit that interfaces with the printer for
accessing EPL or ZPL label forms stored in the printer.
The ZKDU is strictly a terminal and does not have the capability to store data or set up parameters.
The ZKDU is used for the following functions:
• List label forms stored in printer
• Retrieve label forms stored in printer
• Input variable data
• Printing labels
• Switching between EPL and ZPL to dual support both printer language format/form types that can
be stored and printed in many later model Zebra label printers.
ZBI 2.0 ™ — Zebra Basic Interpreter
Customize and enhance your printer using the ZBI 2.0 ™ programming language. ZBI 2.0 allows Zebra
printers to run applications and take input from scales, scanners and other peripherals without a PC or
network connection. ZBI 2.0 works with the ZPL printer command language so that printers can
understand non-ZPL data streams and convert them into labels. That means the Zebra printer can create
barcodes and text from input received, non-ZPL label formats, sensors, keyboards and peripherals.
Printers can also be programmed to interact with PC based database applications to retrieve information to
be used on printed labels.
ZBI 2.0 can be activated by ordering a ZBI 2.0 Key Kit, or activated by purchasing a key from the ZBI 2.0
store at www.zebra.com/software
.
Use the ZDownloader utility to apply the key. Zdownloader at the Zebra Web site: www.zebra.com
.
An intuitive ZBI-Developer ™ programming utility is used to create, test and distribute ZBI 2.0 applications
is available at the Zebra Web site: www.zebra.com
.

Zebra ZD410 Specifications

General

Wi-Fi	Yes
Ethernet LAN	No
Wi-Fi standards	Wi-Fi 5 (802.11ac)
Bluetooth version	4.1
USB 2.0 ports quantity	1
Connectivity technology	Wired & Wireless
Print technology	Direct thermal
Maximum resolution	300 x 300 DPI
Maximum print height	991 mm
Maximum printing width	56 mm
Flash memory	512 MB
Internal memory	256 MB
Built-in barcodes	1D, 2D
Page description languages	EPL, EPL2, XML, ZPL, ZPL II
Display	-
Product color	Gray
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Sustainability certificates	ENERGY STAR
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	5 - 41 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Core diameter	12.7 mm
Media thickness	0.08 - 0.305 mm
Maximum roll diameter	127 mm
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	220 mm
Width	115 mm
Height	151 mm
Weight	1000 g
