Zebra ZD410 User Manual

ZPL Configuration
169
Important • Some factory installed ZPL fonts in your printer cannot be copied, cloned or restored to your printer by
reloading or updating firmware. If these license restricted ZPL fonts are removed by an explicit ZPL object delete
command, they must be repurchased and reinstalled via a font activation and installation utility. EPL fonts do not have
this restriction.
Table 7 Object Management and Status Report Commands
Command Name Description
^WD
Print Directory
Label
Prints a list of objects and resident barcodes and fonts in all
addressable memory locations
~WC
Print Configuration
Label
Prints a configuration Status Receipt (Label)
Same as FEED Button mode one flash routine
^ID
Object Delete Deletes objects from printer memory
^TO
Transfer Object Used to copy an object or group of objects from one
memory area to another.
^CM
Change Memory
Letter Designation
Reassigns a letter designation to a printer memory area.
^JB
Initialize Flash
memory
Similar to formatting a disk - erases all objects from the
specified memory locations B: or E:.
~JB
Reset Optional
Memory
Similar to formatting a disk - erases all objects from the B:
memory (factory option).
~DY
Download Objects Downloads and installs wide variety of printer usable
programming objects: fonts (OpenType and TrueType),
graphics, and other object data types.
Recommendation: Use ZebraNet™ Bridge for downloading
graphics and fonts in the printer.
~DG
Download Graphic Downloads an ASCII Hex representation of a graphic
image. This is used by ZebraDesigner ™ (label creation
application) for graphics.
^FL
Font Linking Appends secondary TrueType font or fonts to the primary
TrueType font to add glyphs (characters).
^LF
List Font Links Prints a list of the linked fonts
^CW
Font Identifier Assigns a single alphanumeric character as an alias to a
font stored in memory.

Zebra ZD410 Specifications

General

Wi-Fi	Yes
Ethernet LAN	No
Wi-Fi standards	Wi-Fi 5 (802.11ac)
Bluetooth version	4.1
USB 2.0 ports quantity	1
Connectivity technology	Wired & Wireless
Print technology	Direct thermal
Maximum resolution	300 x 300 DPI
Maximum print height	991 mm
Maximum printing width	56 mm
Flash memory	512 MB
Internal memory	256 MB
Built-in barcodes	1D, 2D
Page description languages	EPL, EPL2, XML, ZPL, ZPL II
Display	-
Product color	Gray
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Sustainability certificates	ENERGY STAR
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	5 - 41 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Core diameter	12.7 mm
Media thickness	0.08 - 0.305 mm
Maximum roll diameter	127 mm
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	220 mm
Width	115 mm
Height	151 mm
Weight	1000 g
