4、REAR WHELL COMPONENT
38
CHK
ADJ
NO. PART NO. PART NAME QTY CAUTION
3
1244200-130000 ZT310 rear shock absorber KRH oil seal 4 after-sale
4
1250602-038000 ZT310 rear shock absorber KRH needle roller bearing 2
5
1274200-282041 ZT310-VX rear shock linkage rear bushing 1
7
1104100-005000 ZT250-S oil-sealed TC20×26×4 2 after-sale
8
1094100-001000 ZT250-S needle bearing (HK2016) 2
Fig.16 Rear wheel, swinging
arm component
Rear shock absorption 3
1 1274200-306000
ZT310 rear shock-absorbing needle roller bearing
bushing
1
PROCEDURE:
●Rear flat fork connectiong rod assembly
Take off the front bushing⑴.
The oil seal⑶ and needle roller bearing⑷ on the rear flat fork connecting rod assembly ⑵ are all press-fitted
by interference pressure. If there is no malfunction, it is not recommended to disassemble it by yourself.Rear
flat fork connectiong rod assembly⑵ already contains oil seals and bearings.
●Rear shock absorption assembly
Take off the rear bushing⑸.
he oil seal⑶&⑺ and needle roller bearing⑷&⑻ on the rear shock absorption assembly ⑹ are all press-
fitted by interference pressure. If there is no malfunction, it is not recommended to disassemble it by
yourself.Rear shock absorption assembly ⑹ already contains oilseal⑶&⑺ and needle roller bearing⑷&⑻.
CAUTION:
●Suitable grease can be added to reduce resistance at needle roller bearings.
2 4024300-030000
ZT350-VX rear flat fork connecting rod assembly
(including bearing/oil seal)
1
6 4024300-031000
ZT350-VX rear shock absorber connecting rod
assembly (including bearing/oil seal)
1
To Next Page
