7、FRONT FORK COMPONENT
76
CHK
ADJ
NO. PART NO. PART NAME QTY CAUTION
1 1224200-181000 ZT310-VX Windshield Trim
2 ZT310-VX headlight cover
3 1244200-005000
ZT310-R buffer rubber of head cover 5
4 1251300-063093
Plywood M6×11×15(color Zinc) 11
5 1251100-101000
Non-standard bolt M6×12 (304 stainless steel)
5
6 1274100-057095
Flanging bushing φ6.2×φ8.4×3.5
＋
7 1244100-052000 Buffer rubber of flanging bushing (φ8.5×φ14×1) 5
8 1251900-058000 Mushroom buckle (25mm×25mm×T3.5mm) 4
Headlight assembly 5
PROCEDURE:
●Headlight cover sub-assembly
Remove the 6 pieces of splint nuts ⑷ and 5 pieces of head cover cushion rubber ⑶ from the head cover.
Remove the 5 bolts ⑸ with 4# inner hexagon, and remove the bush ⑹ and the cushion rubber ⑺.
Separate the windshield trim ⑴ and the headlight cover ⑵.
The mushroom buckles ⑻ on both sides of the inside are respectively pasted on the headlight cover with
double-sided tape.
CAUTION:
●The parts should be protected during the disassembly process to prevent damage to the paint surface.
●When removing the buckle, pay attention to the strength to prevent damage to the buckle.
Fig.16 FRONT FORK
COMPONENT
