ABB Network Partner AB
Configurable logic
Version 1.0-00
1MRK 580 161-XEN
Page 4 - 36
6.2 Signal list
Table 1: Signal list for the Inverter function
IN: DESCRIPTION:
IVnn-INPUT Logic INV input to INV gate
number nn
OUT: DESCRIPTION:
IVnn-OUT Logic INV output from INV gate
number nn
Table 2: Signal list for the OR function
IN: DESCRIPTION:
Onnn-INPUTm Logic OR input m (m=1-6) to OR
gate number nnn
OUT: DESCRIPTION:
Onnn-OUT Output from OR gate number nnn
Onnn-NOUT Inverted output from OR gate
number nnn
Table 3: Signal list for the AND function
IN: DESCRIPTION:
Annn-INPUTm Logic AND input m (m=1-3) to
AND gate number nnn
Annn-INPUT4N Logic AND input 4 (inverted) to
AND gate number nnn
OUT: DESCRIPTION:
Annn-OUT Output from AND gate number
nnn
Annn-NOUT Inverted output from AND gate
number nnn
