ABB Network Partner AB
Auto-reclosing - Single- and/or
three-phase
Version 1.0-00
1MRK 580 170-XEN
Page 5 - 80
6.2 Signal list Signal list indicating the input and output signals which can be interfaced
with the auto-recloser 1. Data is same for other auto-recloser functions (2
to 6) with signal prefix AR02- to AR06-.
IN: DESCRIPTION:
AR01-TRSOTF Trip from switch-onto-fault
AR01-TPTRIP Three phase trip
AR01-START Protection function trip to AR
AR01-ON Enable auto-recloser
AR01-OFF Disable auto-recloser
AR01-CBREADY CB Ready for operation
AR01-CBCLOSED CB closed
AR01-INHIBIT Inhibit auto-recloser
AR01-PLCLOST Permissive communication channel out of
service
AR01-WAIT Wait from master for sequential reclosing
AR01-SYNC Permission from synchro-check/energizing
check function
OUT: DESCRIPTION:
AR01-CLOSECB Closing command to breaker
AR01-SETON Auto-recloser set on
AR01-INPROGR Auto-reclose operation in progress
AR01-WFMASTER Wait from master for sequential reclosing
AR01-P1PH Permit 1 phase tripping
AR01-P3PH Prepare for 3 phase trip
AR01-READY Auto-reclose ready for new operation
AR01-SP1 1 phase reclosing in progress
AR01-TP1 3 phase, shot 1 in progress
AR01-TP2 3 phase, shot 2 in progress
AR01-TP3 3 phase, shot 3 in progress
AR01-TP4 3 phase, shot 4 in progress
AR01-UNSUC Auto-reclose unsuccessful
