ABB REC 561 User Manual

REC 561 Ordering data sheet
ABB Network Partner AB
1MRK 580 149-XEN
Page 2 - 17
Version 1.0-00
October 1996
Additional in/out modules:
(Totally 11 additional modules can be selected.)
1) Totally up to 6 modules of any combination of binary in/out and binary output
modules can be used in REC 561.
Remote communication (SMS/SCS):
Additional port (SPA)
Transmitter Receiver
Plastic Plastic 1MRK 000 168-FA
Glass Glass 1MRK 000 168-HA
Mounting details with IP40 degree of protection from the front:
19-inch rack 1MRK 000 020-CA
Wall mounting 1MRK 000 020-DA
Flush mounting (IP40) 1MRK 000 020-Y
additional for IP54 1MKC 980 001-2
No mounting details
Accessories:
User’s Guide for REC 561 Quantity: 1MRK 511 009-UEN
Front connection cable
for PC (Opto/9-pol D-sub) Quantity: 1MKC 950 001-1
SMS-BASE, Basic program for
SMS and PC front connection Quantity: RS 881 007-AA
SM/REC 561, SMS Program
module for REC 561 Quantity: 1MRK 000 314-HA
CAP 531, Graphical configuration
tool IEC 1131-3 (requires SMS-
BASE and SM/REC 561) Quantity: 1MRK 000 876-KA
CAP/REC 561, CAP program
module for REC 561 Quantity: 1MRK 000 876-HA
Interface
DC voltage
Quantity
(totally 11)
Ordering number
Binary input modules
(16 inputs)
24/30 V 1MRK 000 508-DA
48/60 V 1MRK 000 508-AA
110/125 V 1MRK 000 508-BA
220/250 V 1MRK 000 508-CA
Binary in/out modules
1)
(8 inputs and 12 outputs
with limited functionality)
24/30 V 1MRK 000 173-GB
48/60 V 1MRK 000 173-AB
110/125 V 1MRK 000 173-BB
220/250 V 1MRK 000 173-CB
Binary output modules
1)
(24 single outputs or 12 command outputs)
1MRK 000 614-AA
mA input modules with 6 channels (up to 6
modules can be selected)
1MRK 000 284-AA
