Direct current measuring unit
ABB Network Partner AB
1MRK 580 154-XEN
Page 7 - 15
Version 1.0-00
8.3 Setting table
Table 3:
PARAMETER: SETTING RANGE: DESCRIPTION:
Name 13 character string Up to 13 characters long name for the measuring channel
Operation Off, On Operation of the measuring channel enabled (On) or disabled (Off)
Calib Off, On Activation (On) or deactivation (Off) of a production calibration. In a
moment only possible to read. The production calibration is always
On.
ChSign Off, On Changes the polarity of connected input current (On)
Unit 5 character string Up to 5 characters long name for the unit of the measuring con-
verter input measuring quantity
Hysteres (0.0-20.0)mA Hysteresis for the set values of the monitoring measuring elements
in one measuring channel.
AlRemove Off, On When On produces an immediate event when any of alarm moni-
toring measuring elements resets.
I_Max (-20.00 - 20.00)mA Determines the maximum permitted input current to the measuring
channel
SampRate (5 - 255)Hz Sampling frequency for the measuring channel
EnAlarm Off, On When On produces an immediate event at operation of any alarm
monitoring measuring elements
MinValue (-1000.00- 1000.00)(a) Determines the minimum value of the measuring transducer pri-
mary measuring quantity, which corresponds to the minimum per-
mitted input current I_Min
HiAlarm (-20.00 - 20.00)mA Determines the operating value of the monitoring measuring ele-
ment, which produces logical signal MInm-HIALARM (n = 1...6 and
m = 1...6)
HiWarn (-20.00 - 20.00)mA Determines the operating value of the monitoring measuring ele-
ment, which produces logical signal MInm-HIWARN (n = 1...6 and
m = 1...6)
LowWarn (-20.00 - 20.00)mA Determines the operating value of the monitoring measuring ele-
ment, which produces logical signal MInm-LOWWARN (n = 1...6
and m = 1...6)
LowAlarm (-20.00 - 20.00)mA Determines the operating value of the monitoring measuring ele-
ment, which produces logical signal MInm-LOWALARM (n = 1...6
and m = 1...6)
RepInt (0-3600)Seconds Duration of time interval between two reports at periodic reporting
function. Setting equal to 0 disables the periodical reporting
EnDeadB Off, On Enables (On) or disables (Off) the amplitude dead band supervision
function
DeadBand (0.00-20.00)mA Width of the amplitude dead band within the ADBS function
EnIDeadB Off, On Enables (On) or disables (Off) the integrating dead band supervi-
sion function
IDeadB (0.00-1000.00)mA Determines the width of the current band within the IDBS function.
Be aware of the sampling frequency.
EnDeadBP Off, On Enables (On) or disables (Off) the periodic dead band reporting
