ABB Network Partner AB
Local man machine
communication
Version 1.0-00
1MRK 580 156-XEN
Page 3 - 24
5 Dialogue window
Fig. 3 Dialogue windows, typical examples
The dialogue windows instruct the operator how to perform the actions
defined by the text in the third and fourth rows. The first and second rows
usually display a headline that provides more information to the user
about the proposed action or the terminal.
The REx 5xx series has five different dialogue windows within each ter-
minal:
• Start window
• Command without a selection
• Command with a selection
• Command with a cancellation
• Command with a selection and a cancellation
5.1 Starting the dialogue Fig. 3a and Fig. 3b show two typical dialogue windows for starting com-
munication with the terminal. Select the:
• C button to clear the LEDs (if required), or
• E button to enter the menu tree
The text (Ready, Start, Trip) in row one of the window in Fig. 3a and Fig.
3b describes the LEDs that are at the top of the display when it is active.
RE.5.. VER 1.0
C=Clear LEDs
E=Enter menu
a)
b)
Trip
Start
Ready
RE.5.. VER 1.0
C=Quit
E=Enter menu
Trip
Start
Ready
(X80156-3)
