8 Characteristics and Specifications
Product Characteristics
236 U3606A User’s and Service Guide
Product Characteristics
POWER SUPPLY
• Universal 100 V
ac
to 240 V
ac
±10%
• AC line frequency 45 Hz to 66 Hz and (360 Hz to 440 Hz, for 100/120 V operation)
POWER CONSUMPTION
150 VA maximum
FUSE
Front panel 3.15 A, 500 V FF fuse
DISPLAY
Highly visible vacuum-fluorescent display (VFD)
OPERATING ENVIRONMENT
• Operating temperature from 0 °C to +55 °C
• Relative humidity up to 80% at 30 °C RH (non-condensing)
• Altitude up to 2000 meters
• Pollution degree 2
• For indoor use only
STORAGE COMPLIANCE
–40 °C to 70 °C
SAFETY COMPLIANCE
Certified with:
• IEC 61010-1:2001/EN61010-1:2001 (2nd Edition)
• Canada: CAN/CSA-C22.2 No. 61010-1-04
• USA: ANSI/UL 61010-1:2004
EMC COMPLIANCE
Certified with:
• IEC 61326-1:2005/EN61326-1:2006
• CISPR11:2003/EN55011:2007, Group 1 Class A
• Canada: ICES/NMB-001:2004
• Australia/New Zealand: AS/NZS CISPR 11:2004
SHOCK AND VIBRATION
Tested to IEC/EN 60068-2
REMOTE INTERFACE
• GPIB IEEE-488 compatible
• Full Speed USB 2.0 (Standard-A to Type-B)
• USBTMC 488.2 Class device compatible
• USB-CDC
