1Getting Started
Product at a Glance
12 U3606A User’s and Service Guide
AC+DC measurement selected
ºC Celsius temperature unit (feature not applicable with the U3606A)
ºF Fahrenheit temperature unit (feature not applicable with the U3606A)
dB Decibel unit relative to 1 dBm
dBm Decibel unit relative to 1 mW
ms Pulse width unit
% Duty cycle unit
MkΩ Resistance units: Ω, kΩ, MΩ
MkHz Frequency units: Hz, kHz, MHz
mV Voltage units: mV, V
mA Current units: mA, A
μnF Capacitance units: nF, μF
EXT Remote sensing mode enabled
CC Constant current mode selected
CV Constant voltage mode selected
Lo Ω Low-resistance (4-wire) measurement selected
Square-wave output selected
S1 Output range S1 selected — 30 V/1 A
S2 Output range S2 selected — 8 V/3 A
V Voltage unit: V for constant voltage mode
A Current unit: A for constant current mode
Hz Frequency unit: Hz for square-wave output
LOG Data logging in progress (feature not applicable with the U3606A)
Store Store instrument state selected
Recall Recall instrument state selected
Table 1 - 1 U3606A display annunciators (continued)
Annunciator Description
