Check the transmission fork cam roller
«1» and the transmission fork tooth
«2» for damage, deformation and
wear.
•
Replace the transmission fork if nec-
essary.
•
Check the transmission fork movement and if it is not regular, replace the transmission forks.
Assembling the gearbox
•
Place the drum (1) of the gear selector
on the support and insert the desmo-
dromic shaft (2), paying attention to
correspond the operations on both
components
•
Position and tighten the screw (3) fixing
the drum to the desmodromic shaft
CAUTION
SECURE THE SHIM WASHER (4) TO THE SECONDARY
SHAFT WITH GREASE
RSV4 RR-RF Engine
ENG - 279
