APRILIA RSV4 RR 2017 User Manual

CLUTCH
Pos. Description Type Quantity Torque Notes
1 Flanged nut fixing clutch M20x1 1 150 Nm (110.63 lb ft) Loct. 243
2 Clutch springs SHC fixing screw M6x25 6 10 Nm (7.38 lb ft) -
Removing the clutch cover
•
Drain the engine oil.
•
Unscrew and remove the five special screws (1) to remove the soundproof cover (2).
•
Unscrew and remove the five special
screws (3) and the eleven fastening
screws (4) around the perimeter, and
retrieve the relative washers.
Engine RSV4 RR-RF
ENG - 292
