Position the new bearings with their
groove on the outside diameter facing
outward with respect to the crankcase.
In this way it will be possible to install
the bearing retainer in the groove.
•
Using the suitable tools, fit the bearing
in the crankcase until tool stops.
•
Fit the retainer in the bearing groove.
•
Tighten the bearing retainer screw.
•
Install the balancing countershaft.
Crankshaft fitting
When refitting the primary gear, remember to first
place the lining as shown in the figure. The greater
diameter side is facing outwards the engine.
Engine RSV4 RR-RF
ENG - 366
