APRILIA RSV4 RR 2017 User Manual

•
Remove the metal gasket central fixing
screw
•
Remove the metal gasket
•
Remove the lower gasket
•
Remove the overpressure valve together with gasket
Blow-by
The Blow-by system uses the rotation of the countershaft (1) to separate the engine oil into oil vapour
and liquid.
Engine RSV4 RR-RF
ENG - 380

APRILIA RSV4 RR 2017 Specifications

General

Displacement	999.6 cc
Bore x Stroke	78 x 52.3 mm
Compression Ratio	13.6:1
Transmission	6-speed
Frame	Aluminum dual beam chassis with pressed and cast sheet elements
Tires	Pirelli Diablo Supercorsa SP
Front Tire	120/70 ZR17
Rear Tire	200/55 ZR17
Engine Type	65° V4
Power	201 hp
Torque	115 Nm
Fuel System	Electronic fuel injection
Clutch	Multiplate wet clutch
Rear Suspension	Ohlins TTX shock
Front Brakes	Brembo 320 mm discs, radial calipers
Rear Brakes	Brembo 220 mm disc
ABS	Bosch 9MP ABS
Fuel Capacity	18.5 liters
Wheelbase	1420 mm
