Coating may get slightly damaged in the indicated
area.
Valve installation
The intake valves are fitted with dual springs, while
he exhaust valves only have a single spring.
The intake springs are marked in orange (1) (ex-
ternal) and blue (2) (internal), whereas the exhaust
springs (3) are marked in white.
•
Lubricate the valve stem and insert the
valves on the valve guide.
•
Position the springs with the closest
turns facing the head of the valve
CAUTION
THE INTAKE VALVES HAVE A DOUBLE SPRING WHERE-
AS THE EXHAUST VALVES HAVE A SINGLE SPRING.
RSV4 RR-RF Engine
ENG - 343

APRILIA RSV4 RR 2017 Specifications

General

Displacement	999.6 cc
Bore x Stroke	78 x 52.3 mm
Compression Ratio	13.6:1
Transmission	6-speed
Frame	Aluminum dual beam chassis with pressed and cast sheet elements
Tires	Pirelli Diablo Supercorsa SP
Front Tire	120/70 ZR17
Rear Tire	200/55 ZR17
Engine Type	65° V4
Power	201 hp
Torque	115 Nm
Fuel System	Electronic fuel injection
Clutch	Multiplate wet clutch
Rear Suspension	Ohlins TTX shock
Front Brakes	Brembo 320 mm discs, radial calipers
Rear Brakes	Brembo 220 mm disc
ABS	Bosch 9MP ABS
Fuel Capacity	18.5 liters
Wheelbase	1420 mm
