Remove the front mudguard.
Instrument cluster support
REMOVAL
•
Remove the instrument panel.
•
Working on both sides, unscrew and
remove the two screws fastening the
arch brace to the headstock.
•
Retrieve the cable grommet.
•
Unscrew and remove the five semi-
arch brace fixing screws.
See also
Instrument panel
Bodywork RSV4 RR-RF
BODYW - 542
