CLUTCH-SIDE
•
Unscrew and remove the bearing re-
tainer screw.
•
Remove the lock.
•
Heat up the crankcase to 150°C (302°
F).
•
Position the general tool to pull out
bearings.
•
Remove the bearing.
Crankshaft check
Characteristic
Maximum crankshaft axial clearance after
closing the crankcase
0.40 - 0.10 mm (0.0157 - 0.0039 in)
Maximum radial play between main bushings
and crankpins
0.07 mm (0.00275 in)
Balancing countershaft check
Characteristic
Maximum countershaft axial clearance after closing the crankcase
0.1 mm (0.0039 in)
Engine RSV4 RR-RF
ENG - 358
