APRILIA RSV4 RR 2017 User Manual

•
Install the countershaft gear aligning
the references on the countershaft
gear and the primary shaft gear.
NOTE
THE BURIN ON THE PRIMARY SHAFT GEAR TOOTH MUST
BE INSERTED INTO THE SLOT IDENTIFIED WITH TWO
BURINS ON THE COUNTERSHAFT GEAR.
•
Insert the countershaft from the alter-
nator side.
•
Turn the countershaft until aligning the
key seat on the countershaft and on the
gear.
•
Insert the drive key.
•
Place the washer.
•
Turn the nut on the countershaft.
•
Block crankshaft rotation using the
specific tool.
•
Tighten the nut on the countershaft.
Specific tooling
020849Y Clutch lock
Engine RSV4 RR-RF
ENG - 350

APRILIA RSV4 RR 2017 Specifications

General

Displacement	999.6 cc
Bore x Stroke	78 x 52.3 mm
Compression Ratio	13.6:1
Transmission	6-speed
Frame	Aluminum dual beam chassis with pressed and cast sheet elements
Tires	Pirelli Diablo Supercorsa SP
Front Tire	120/70 ZR17
Rear Tire	200/55 ZR17
Engine Type	65° V4
Power	201 hp
Torque	115 Nm
Fuel System	Electronic fuel injection
Clutch	Multiplate wet clutch
Rear Suspension	Ohlins TTX shock
Front Brakes	Brembo 320 mm discs, radial calipers
Rear Brakes	Brembo 220 mm disc
ABS	Bosch 9MP ABS
Fuel Capacity	18.5 liters
Wheelbase	1420 mm
