Tap the wheel axle slightly to extract
the head from its seat.
•
Make the wheel move forward and re-
lease the gearing chain from the
sprocket.
•
Remove the wheel spindle together
with the right hand chain tensioner
skid.
•
Remove the wheel by freeing the disc
from the brake calliper.
Parastrappi
REMOVAL
•
Remove the final transmission unit
NOTE
THE FLEXIBLE COUPLINGS REMAIN FITTED ON THEIR
WHEEL
REMOVAL
•
Place the final transmission unit on a
vice
TO PROTECT THE CROWN GEAR, INSTALL (WOODEN OR
ALUMINIUM) PROTECTIONS ON THE VICE JAWS. LOCK
THE CROWN GEAR ONLY IN A VICE. DO NOT LOCK ANY
OTHER COMPONENT OF THE FINAL TRANSMISSION
UNIT.
Suspensions RSV4 RR-RF
SUSP - 424
