12. Color calibration
12.1 Calibration process
Overview
1. Select the desired aspect ratio by activating the c orrect lens file.
- SCOPE format
- FLAT format
2. Color gamut calibration. (electronic P7 correction). Meas ured values are saved in the Measured Color Gamut Data (MCGD)
file. Needs to be done per format and per projection mode.
-2D
- External 3D
3. Select target colors. The target colors are stored in the Target Color Gamut Data (TCGD) file. Several TCG D files are a
lready
available in the file system of the projector.
For more info about color gamut calibration see "Color gam ut calibration", page 115. The Com m unicator software contains a
wizard for color gamut calibration. See user guide of the Communic ator for detailed menu navigation instructi
ons.
4. Verify corrected colors.
For detailed instructions on how to verify corrected colors see user guide of Communicator.
5. Arrange calibration files in macro. To apply correct color calibration it is important that the MCG D file(s) and matching TCGD
file(s) are activated after that the INP UT file and PCF file are activated. F or that it is recommended to c reate a macr o wher e the
files are loaded one by one in the right order:
a) First activate the INPUT file.
b) then activate the PCF file (PCF already contains plane 1 information),
c) then activate the MCGD and TCGD files.
For detailed instructions on how to create a m acro see Commu nicator ’s user guide.
114
R5906847 DP2K SLP SERIES 02/06/2017
