7. ICMP
7.5 ICMP DisplayPort specifications
DisplayPort
Digital display interface developed by the Video Electronics S tandards Association (VESA). This royalty-free interface
is primarily used to c onnect a video source to a display device such as a computer monitor, though it can also be used
to transmit audio, USB, and other forms of data. VESA designed it to replace VGA, DVI, and FPD-Link. B ackwa rd
compatibility to V G A and DVI by using active adapter dong les enables users to use DisplayPort fitted video sources
without replacing existing display devices.
HDCP
High-bandwidth Digital Content Protection is a form of digital copy protection dev eloped by Intel Corporation to p revent
copying of digital audio and v ideo content as it travels across DisplayPort, Digital Visual Interface (DV I), High-Definition
Multimedia Interface (HDMI), G igabit Video Interface (GVIF), or Unified Display Interface (UDI) connections, even if
such copying would be pe rmitted by fair use laws. The s pecific ation is proprietary, and implementing HDCP requires
a license.
DisplayPort specifications
Supported Modes:
• DP1.1a, 4-lanes RBR/HBR
• Audio : yes
• Content Protection : HDCP1.4
• Color Depth : 8 bit/component and 1 0 bit/component.
• 3D-stereo mode : frame sequential (embedded stereosync on DP required from the s ource)
DisplayPort A and DisplayPort B accept the following video-timings:
2D Formats / Single DP Color depth Port Display Mode
640 x 480 @ 60 fps 8 bpc, 10 bpc Single 2D
800 x 600 @ 60 fps 8 bpc, 10 bpc Single 2D
1600 x 1200 @ 60 fps 8 bpc, 10 bpc Single 2D
1280 x 800 @ 60 fps 8 bpc, 10 bpc Single 2D
1280 x 720 @ 60 fps
8 bpc, 10 bp c
Single
2D
1680 x 1050 @ 60 fps
8 bpc, 10 bp c
Single
2D
1920 x 1080 @ 60 fps
8 bpc, 10 bp c
Single
2D
1920 x 1200 @ 60 fps
8 bpc, 10 bp c
Single
2D
2048 x 1080 @ 48, 60 fps
8 bpc, 10 bp c
Single
2D
2048 x 1536 @ 60 fps
8 bpc, 10 bp c
Single
2D
2048 x 2160 @ 30, 48, 50, 60 fps
8 bpc, 10 bp c
Single
2D
3840 x 2160 @ 24 fps
8 bpc, 10 bp c
Single
2D
3D Formats / Single DP Color depth Port Display Mode
1920 x 1080 @ 60 fps 8 bpc, 10 bpc Single 3D
2048 x 1080 @ 60 fps 8 bpc, 10 bpc Single 3D
4K Horizontal SPAN 2D - Full Color depth Port Display Mode
2048 x 2160 @ 30, 48, 50, 60 fps
8 bpc, 10 bp c A+B span 2D
4K Horizontal SPAN 2D - Flat Color depth
Port Display Mode
1920 x 2160 @ 30, 48, 50, 60 fps
8 bpc, 10 bp c A+B span 2D
4K Horizontal SPAN 3D Color depth
Port Display Mode
2048 x 2160 @ 60 fps
8 bpc, 10 bp c A+B span 3D
60
R5906847 DP2K SLP SERIES 02/06/2017
