7. ICMP
7.10 ICMP H DD status LEDs
ICMP HDD status LEDs
54
Image 7-11
Status overview P W R/ERROR and READY LED s:
4 5
HDD I/O
RAID
ICMP HDD Status
Off Off HD D idle / Disk in RAID OK.
Blinking Green Off HD D I/O activity / Disk in RAID OK .
Blinking Green
Blinking Red
HDD I/O activity / R AID rebuilding.
Off Red HDD idle / Disk error. See troubleshooting table below for curative ac tions.
Troubleshooting
Situation Solution
Onediskfailed(redLED)+RAID degraded.
The ongoing event is not interrupted.
Note: The disk status (RAID degraded) ca n be retrieved via the
(Web) Commander. S ee user guide of the (Web) Com mander.
1. Switch off the power.
2. Replace the defect HDD with an original HDD spare part.
See procedure "Removing a HDD from the ICMP", page
79, and "Installing a HDD into the ICMP", page 80. E n sure
to insert the HDD firmly.
3. Switch on the power.
Result: As soo n the new HDD is detected by the ICMP the
rebuild of the RAID is started (Blinking red LED).
One disk failed (red LED) + E rror 10580 “local storage not
available”.
Note: The disk status ( Error code) can be retrieved via the
(Web) Commander. S ee user guide of the (Web) Com mander.
1. Switch off the power.
2. Replace the defect HDD with an original HDD spare part.
See procedure "Removing a HDD from the ICMP", page
79, and "Installing a HDD into the ICMP", page 80. E n sure
to insert the HDD firmly.
3. Switch on the power.
Result: As soo n the new HDD is detected by the ICMP the
rebuild of the RAID is started (Blinking red LED).
Multiple disks f ailed (multiple red LEDs) + RAID broken.
Note: The disk status (RAID broken) can be retrieved via the
(Web) Commander. S ee user guide of the (Web) Com mander.
1. Switch off the power.
2. Replace all defect HDDs with original HDD spare parts.
See procedure "Removing a HDD from the ICMP", page
79, and "Installing a HDD into the ICMP", page 80. E n sure
to insert the HDDs firm ly.
3. Switch on the power.
4. Start “RAID Initialize”. S ee user guide of the
Communicator.
Result: a new empty RAID is c reated.
All HDD LEDs remain off + Error 10580 “local storage not
available”.
Note: The disk status ( Error code) can be retrieved via the
(Web) Commander. S ee user guide of the (Web) Com mander.
1. Switch off the power.
2. Reseat all HDDs. See procedure "Removing a HDD from
the ICMP", pag e 79, and "Installing a HDD into the ICMP",
page 80. E nsure to insert the HDD s firm ly
.
3. If problem remains try “RAID Initialize”. See user guide of
the Comm unicator. Note that all content will be lost!
4. If problem remains contact Service for further instructions.
72 R5906847 DP2K SLP SERIES 02/06/2017
