15. Removal and installation of the projector covers
15. R EMOVAL AND INSTALLATION OF THE PROJEC TOR
COVERS
About this chapter
Most installation, maintenance and service procedures demand removing one or m ore of the pro jector covers to gain access to the
parts to maintain or to service. To avoid redundancy, all procedures about cover removing or installing are grouped toge ther in this
chapter. The maintenance and servicing procedures also refer to this chapter if required. Th e
procedures in this chapter des cribe,
with detailed s tep by step actions and illustrations, how to remov e or install the projector covers. Note that the c overs may only be
removed by qualified service personnel.
WARNING: All pro cedures d escribed in this chapter may only be performed by TRAINED PROJECTION ISTS
or qualified SERVICE PERSONNEL.
WARNING: Always sw itch off the projector and unplug the power cord b efore removing one of the co vers,
unless otherwise stated.
Overview
• Removal of the Light S ource cover
• Removal of the rear cover
• Removal of the top cover
• Removal of the left s ide cover
• Removal of the top c over plate of the Light Processor compartment
• Removal of the side cover plate of the Light Processor compartment
• Installation of the side cover plate of the Light Processor compartmen t
• Installation of the top cover plate of the Light Processor compartment
• Installation of the left side cov er
• Installation of the top cover
• Installation of the rear cover
• Installation of the Light Source cover
R5906847 DP2K SLP SERIES 02/06/2017
