3. Installation process
3.1 Installation process overview
Installation process Projector
1. Check if all installation requirements are fulfilled such as the environmen t conditions of the installation area, electrical facili-
ties, etc. N ote that a solid pedestal is required to su pport the projector. For more info s ee topic installation requirem ents.
2. Physical installation o f the pro jector upon its pedestal.
3. Electrical connection with the power net. See "Conne cting the projector with the power net", page 31.
4. Installation of t he lens. Firs t select a lens with appr opriate throw r atio covering the screen size and the pro jector - screen
distance. Then install the lens in the lens holder of the projector. For more information about available lenses, lens selection and
lens installation see chapter "Lens installation", page 36.
Caution: The projector is delivered with a plastic cover inside the Lens Holder. Remove the cover prior to installing the lens.
5. Installation of the ICMP, IMB, IMS or HDSDI input mo dule. (only in case no ICMP, or IMB or IMS or HDSDI is factory installed).
6. Installation of the HDDs. In case the HDDs of the ICMP are delivered separated from the projector remove the p rotection tape
from the HDD input s lots and install all three HDDs as described in the procedure"Installing a HDD into the ICMP", pa ge 80.
Make sure that all HDDs in the ICMP H D D set have the s ame storage capacity. See label on top of the HDD to know the storage
capacity.
7. Installation of the optional Comm unicator Touch Panel. See c hapter "Installing the Touch Panel interface", page 86.
8. Upgrade all software to the latest av ailable version. See "Software upgr ade", page 25.
9. Start up your projector and adjust the system. See "Starting up and adjusting the system", page 26.
24
R5906847 DP2K SLP SERIES 02/06/2017
