MY23P0a -52_1.0_11.10.2022
128
Operation
6.4 Instruction and customer service
The supplying specialist dealer will provide
customer service. Contact details can be found on
the pedelec pass for these operating instructions.
The specialist dealer will explain all the pedelec
functions to the new owner in person, this being
when the specialist dealer hands over the pedelec
at the latest. These operating instructions are
provided with every pedelec, so that the rider can
consult them at a later stage.
The supplying specialist dealer will also perform
all inspection, modifications and repairs in the
future.
6.5 Adjusting the pedelec
Only a correctly adjusted pedelec will guarantee
the desired ride comfort and health-promoting
activity.
All settings must be re-configured if the body
weight or maximum baggage weight changes.
6.5.1 Preparing
The following tools are required to adjust the
pedelec:
Crash caused by incorrectly adjusted torque
If a screw is fastened too tightly, it may break. If a
screw is not fastened enough, it may loosen. This
will cause a crash with injuries.
Always observe the torque indicated on the
screw and in the operating instructions.
Tape measure
Scales
Spirit level
Ring spanners
8 mm, 9 mm, 10 mm, 13 mm, 14 mm und 15 mm
Torque wrench
Working range 5… 40 Nm
Hex key
2 mm, 2.5 mm, 3 mm, 4 mm, 5 mm, 6 mm and
8 mm
Cross-recess screwdriver
Slotted-head screwdriver
Table 52: Tools required for assembly
