MY23P0a -52_1.0_11.10.2022
177
Operation
6.9 Straightening the quickly
adjustable stem
Only applies to pedelecs with this equipment
1 Open stem clamping lever.
Figure 158: Example of All Up with open stem clamping
lever
2 Pull handlebars into the highest possible
position.
Figure 159: Example of All Up pulled into highest possible
position
3 Turn handlebars 90° anti-clockwise so that
they are straight.
Figure 160: Example of All Up in straight position
4 Place handlebars at required height.
5 Close stem clamping lever.
6.10 Using the pannier rack
Distribute the baggage as evenly as possible
between the left- and right-hand side.
We recommend the use of panniers and
baggage baskets.
Crash caused by loaded pannier rack
The pedelec is handled differently with a loaded
pannier rack, in particular when the rider needs to
steer and brake. This can lead to a loss of control.
This may cause a crash with injuries.
You should practice how to use a loaded
pannier rack safely before using the pedelec in
public spaces.
Crushing the fingers in the spring flap
The spring flap on the pannier rack operates with
a high clamping force. There is a risk of crushing
the fingers.
Never allow the spring flap to snap shut in an
uncontrolled manner.
Be careful where you position your fingers
when closing the spring flap.
Crash caused by unsecured baggage
Loose or unsecured objects on the pannier rack,
e.g. belts, may become caught in the rear wheel.
This may cause a crash with injuries.
Objects which are fastened to the pannier rack
may cover the reflectors and the riding light. Other
users may not see the pedelec on public roads as
a result. This may cause a crash with injuries.
Secure any objects which are attached to the
pannier rack sufficiently.
Objects fastened to the pannier rack must
never cover the reflectors, the headlight or the
rear light.
