Troubleshooting, fault clearance and repair
9.2.9 Problems with SR SUNTOUR rear frame damper
9.2.9.1 Rebound too fast
The rear frame damper rebounds too quickly,
producing a "pogo stick" effect or causing the bike
to bounce after the wheel hits a bump and lands
on the ground again. This impairs traction and
control due to the uncontrolled speed at which the
rear frame damper rebounds after deflecting
(blue line).
Saddle and handlebars are deflected upwards
when the wheel bounces back from the ground.
The rider's body weight may be shifted upwards
and forwards if the rear frame damper fully
rebounds too quickly (green line).
Figure 234: Rear frame damper rebounding too quickly
Solution
Turn rebound adjuster wheel towards plus. The deflection movement is reduced.
Figure 235: Position of RS Suntour rebound adjuster wheel for rear frame dampers Triair2 (a), Triair (b), EDGE-comp (c),
EDGE (d) and RAIDON (e)
