Bosch Intuvia 100 User Manual

MY23P0a -52_1.0_11.10.2022
276
Documents
11 Documents
11.1 Assembly report
Date:
Frame number:
Components Description Criteria Measures if rejected
Assembly/
inspection
Tests
Accept-
ance
Rejection
Front wheel Assembly O.K. Loose Adjust quick release
Kickstands Check mount fastening Functional check O.K. Loose Retighten screws
Tyres Tyre pressure check O.K.
Tyre pressure too low/
too high
Adjust tyre pressure
Frame
Check for damage –
fracture, scratches
O.K. Damage detected Take out of operation, new frame
Handles, coverings Check mount fastening O.K. Not provided
Retighten screws, new handles
and coverings as specified in
parts list
Handlebars, stem Check mount fastening O.K. Loose
Retighten screws; new stem as
specified in parts list if necessary
Steering headset Check for damage Functional check O.K. Loose Retighten screws
Saddle Check mount fastening O.K. Loose Retighten screws
Seat post Check mount fastening O.K. Loose Retighten screws
Guard Check mount fastening O.K. Loose Retighten screws
Pannier rack Check mount fastening O.K. Loose Retighten screws
Attachments Check mount fastening O.K. Loose Retighten screws
Bell Functional check O.K. No ring, too quiet, missing
New bell as specified in the parts
list
Suspension elements
Fork, suspension
fork
Check for damage O.K. Damage detected
New fork as specified in the parts
list
Rear frame damper Check for damage O.K. Damage detected
New fork as specified in the parts
list
Suspension seat post Check for damage O.K. Damage detected
New fork as specified in the parts
list
Brake system
Handbrake Check mount fastening O.K. Loose Retighten screws
Brake fluid Check fluid level O.K. Too little
Refill with brake fluid; new brake
hoses if damaged
Brake linings
Check brake linings,
brake discs and rims for
damage
O.K. Damage detected
New brake linings, brake discs
and rims
Back-pedal brake
braking armature
Check mount fastening O.K. Loose Retighten screws
Lighting system
Rechargeable battery First examination O.K. Error message
Take out of service; contact
battery manufacturer, new battery
Light cabling
Connections, correct
wiring
O.K. Cable defective, no light New cabling
Rear light Side light Functional check O.K. No constant light
Take out of service; new rear
light as specified in parts list;
replace if necessary
Front light
Side light, daytime riding
light
Functional check O.K. No constant light
Take out of service; new front
light as specified in parts list;
replace if necessary
Reflectors
All complete, state,
fastening
O.K.
Damaged or not all
complete
New reflectors
