MY23P0a -52_1.0_11.10.2022
297
Documents
11.3.6 Premio EVO 5F Lite Belt Comfort
23-15-2090, 23-15-2092
Gent, Wave
Frame
PEGASUS, FM-Z-70A23324 Aluminium, welded, frame shape and size:
Gent: S=45/M=50/L=55/XL=60 cm
Trapez: L:S=45/M=50/L=55
Rear frame damper
… …
Tyres
Front | Rear
SCHWALBE, Marathon E-Plus Road tyres
Smart DualGuard®
EPI: 67
Profile: HS498
Clincher
Weight: 1395 g
Size: 55-622 (28")
Max. load: 136 kg
Printing: 2.0-4.0 bar (30-55 psi)
Tube
SCHWALBE, DV19 40 mm Dunlop valve, valve length: 40 mm
Wheel
… …
Rims
Pegasus, TAURUS 2000 Aluminium, 700C, 14G × 36H
Spokes
…/XT344 Corrosion-resistant, 14G × 36H/13G-14G × 36H
Spoke nipples
… Brass, 14G × 36H
Front wheel hub
SHIMANO, ALTUS HB-MT400 Aluminium, front wheel hub, with centre lock,
with quick release axle (by fork manufacturer) 15 mm,
with E-Thru quick release axle, 15 mm, 32H
Rear wheel hub
SHIMANO, Nexus SG-C7000-5D Gear hub, 5-speed, centre lock, 36H, free-wheeling
Steering headset
FSA, no. 83RO/SC/1.5" Aluminium, Aheadset, conical, for fork steerer: 1.5"
Stem
KALLOY, AS-ZGD2 Aluminium, Ahead stem, adjustable,
Handlebars clamp diameter: Ø 31.8 mm
Stem length: Frame size: 45/50/55: 90 mm
Frame size: >55: 110 mm
Handlebars
SATORI, BUTTERFLY Aluminium, Ø 31.8 mm, height: Length: 683 mm
Handles/tapered
Left hand | Right hand
VELO ENTERPRISE, VLG-2009AD2-L/
VLG-2009AD2-R
Left: 157.1/180 × 151.6 mm
Right: 157.3/130.1 × 151.6 mm
Fork
SR SUNTOUR, MOBIE25 DS LOR AIR
700C
Steel suspension fork
Right side: LOR cartridge
Left side: air-suspended with adjustable pre-tensioning
Deflection: 63 mm
Stanchion distance: 518.5 mm
Offset: 415 mm
Head tube: 1-1/8"
Axle: Ø: 9; length: 100 mm 15QLC32
Fork remote control
SR SUNTOUR, XCM32-ATB DS NLO 29" Lockout operation on the crown
Saddle
VELO ENTERPRISE, VL-6483 Men’s saddle
Seat post
SR SUNTOUR, SP17-NCX Aluminium, parallel seat post,
Ø: 31.6 mm
Deflection: 40 mm
Length: 400 mm
Rider weight 65
