MY23P0a -52_1.0_11.10.2022
73
Description
1. Selected level of assistance indicator
The higher the selected level of assistance, the
more the drive system assists with pedalling.
eMTB mode is available for Performance Line CX
drives. In eMTB mode, the assistance factor and
the torque are dynamically adjusted depending on
the pedalling force applied to the pedals.
2. ABS indicator (optimum)
The ABS indicator lights up on pedelecs with an
ABS system when they start up.
The ABS will switch off if the pedelec reaches a
speed of 6 km/h.
If there is a fault, the ABS indicator lights up
together with the indicator of the selected level of
assistance, which will flash orange.
Press the Select button to acknowledge the fault
and the flashing indicator for the selected level of
assistance will go out. The ABS indicator remains
lit to indicate that the ABS system is not in
operation.
3. Battery level indicator (on-board computer)
The battery level indicator (on-board computer)
shows the battery charge level. You can also see
the battery charge level on the LEDs on the
battery itself.
Each blue bar on the indicator signals 20%
capacity and each white bar 10% capacity. The
top bar indicates maximum capacity. The two
lower indicators will change colour if the capacity
is low:
The uppermost bar will flash if the battery is
charging.
3.4.2.1 System message
The on-board computer indicates whether a
critical or less critical error has arisen in the drive
system.
The error messages generated by the drive
system can be read in the eBike Flow app and by
the specialist dealer.
The rider can use a link in the eBike Flow app to
display all information on errors and assistance on
eliminating errors.
You will find more information and a table
containing all system messages in Section 6.2.
Level of assis-
tance
Colour Use
OFF No When the drive system is
switched on, the motor
assistance is switched off.
Use the pedelec like a
normal bicycle by simply
pedalling
ECO Green Limited assistance with
maximum efficiency for
maximum range
TOUR blue Constant assistance, for
long-range tours
eM TB / S PO RT
Purple Powerful assistance, for
sporty start-up, optimal
assistance on all types of
terrain
TURBO Red Maximum assistance up to
high pedalling frequencies,
for sport riding
Table 23: Overview of level of assistance
Bars Capacity
5 × blue 100 … 91%
4 × blue + 1× white 90 … 81%
4 × blue 80 … 71%
3 × blue + 1× white 70 … 61%
3 × blue 60 … 51%
2 × blue + 1× white 50 … 41%
2 × blue 40 … 31%
2 × orange 30 … 21%
1 × orange 20 … 11%
1 × red 10% … reserve
1 x red, flashing Reserve … empty
