Rated maximum current in
conductor (A)
Separation distance (m)
10 0.05
30 0.16
For conductors rated at a maximum current not listed above, the recommended separa-
tion distance d in metres (m) can be estimated using the equation d=I/2?H, where I is
the maximum current rating of the conductor in amperes (A) according to the transmit-
ter manufacturer; H is the ventilator immunity compliance level to electromagnetic
fields in the 50-60 Hz frequency span (30 A/m).
8.3.6 Recommended separation distances between external power
conductors and the ventilator
Rated maximum current in
conductor (A)
Separation distance (m)
50-60 Hz d= I/2πH= I/188
1 0.005
10 0.05
30 0.16
For conductors rated at a maximum current not listed above, the recommended separa-
tion distance d in metres (m) can be estimated using the equation d=I/2?H, where I is
the maximum current rating of the conductor in amperes (A) according to the transmit-
ter manufacturer; H is the ventilator immunity compliance level to electromagnetic
fields in the 50-60 Hz frequency span (30 A/m).
8.4 Delivery Settings
Delivery settings: modes and functions
Ventilation Mode: Pressure
Breath Mode: Support
Patient Mode: Adult
Device Mode: Clinical
Home Adjust: Off
Profile 1: Active
Profile 2: Off
Profile 3: Off
Technical Specifications 157
Doc. 006149 D-3
Vivo 45 User manual
