5.2.4 Display Overview
This section describes the areas on the display.
1. Title and Icons
Ventilation mode, breath mode, patient mode and device mode are displayed. When
more than 1 profile is used, the active profile is displayed.
2. Pressure and Volume Indicators
The bar graphs are used to display current pressure, PEEP, Ppeak, pressure and vol-
ume alarm limits, and expired tidal volume.
The red lines represent the low and high pressure alarms, the low and high tidal vol-
ume alarms.
3. Icons/Alarm Message
Information icons are presented here to give a quick overview of the Vivo 45 basic
status (see 5.2.2 Symbols Used in the Menu, page 49).
4. Monitoring Field
This field is designed to give a brief overview of the key monitor values. Navigate to
the Monitor section for the all available values.
5. Screen Title and Context Area
This field displays settings and information for the section. Screen title, page num-
ber (if more than one sub page exists in the section) and time are also displayed.
6. Navigation Field
This field is mainly used for displaying the section layout of the menu, and deter-
mines the function of each navigation button. Depending on current operation, the
navigation buttons can be assigned temporary functions such as “Yes” or “Next”,
depending on which operation is active.
52 How to Use the Vivo 45
Vivo 45 User manual
Doc. 006149 D-3
