Important
• If you access the printer driver dialog box from the operating system menu, changes you make to the settings will
apply to all applications you use for printing.
• You can also access the printer driver dialog box from applications.
(See "Accessing the Printer Driver Dialog Box from Applications .") ➔ P.164
Main Sheet
Main Sheet
The following settings are available on the Main sheet. For details on settings items, refer to the printer driver help file.
Note
• On the Main sheet, choose Easy Settings to specify basic print settings based on the particular printing application, or
switch to Advanced Settings to complete more detailed settings as desired.
Common Items
• A Media Type
Select the type of paper.
For information on the types of paper the printer supports, refer to the Paper Reference Guide. (See "Displaying
the Paper Reference Guide.") ➔ P.363
• B Get Information
Displays Paper Information on Printer. You can update the printer driver settings for the feed source, media
type, and roll width by selecting the feed source.
• Paper Information on Printer Dialog Box ➔ P.170
• C Advanced Settings
Displays Paper Detailed Settings. You can configure the printing settings to match the type of media, such as the
ink drying time.
• Paper Detailed Settings Dialog Box ➔ P.170
• L
Open Preview When Print Job Starts
When the check box is selected, imagePROGRAF Preview is launched before printing.
This allows you to check on-screen previews of documents before printing.
• Checking the Layout in a Preview Before Printing ➔ P.144
• M
Status Monitor
Starts imagePROGRAF Status Monitor.
You can check the printer status, job status, and other conditions.
iPF680
Main Sheet
User's Guide
Windows Software Printer Driver
167

Canon imagePROGRAF iPF680 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Page description languages	GARO, HP-GL/2, HP-RTL
Media thickness	0.07 - 0.8 mm
Maximum print size	-
Maximum roll length	18 m
Media width (rolls)	254 - 609.6 mm
Media width (sheets)	203.2 - 609.6 mm
Maximum roll diameter	150 mm
Paper tray media types	Coated paper, Cut sheet, Plain paper, Roll
ISO A-series sizes (A0...A9)	A1, A2, A3
ISO B-series sizes (B0...B9)	B2, B4
Certification	RoHS
Product color	Black, Grey
Sound pressure level (printing)	47 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10/100/1000 Base-T/TX Mbit/s
Ethernet interface type	Gigabit Ethernet
Compliance industry standards	IEEE 802.3ab, IEEE 802.3u, IEEE 802.3
Power consumption (standby)	0.5 W
Power consumption (typical)	140 W
Storage temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	20 - 80 %
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	757 mm
Width	997 mm
Height	507 mm
