Setting Item Details
20 mm (0.8 in) Select this when rubbing against the printhead occurs such as when using paper that tends
to curl.
F Cut Speed
Select the speed of automatic cutting, as needed. You can adjust this setting if paper is not cut well when automatic
cutting is used.
Setting Item Details
Printer Default The setting of the control panel of the printer is applied.
High Speed When the Standard setting does not result in cutting the surface cleanly, select this.
Standard Select this when you do not have any problems in automatic cutting.
Low Speed This helps prevent adhesive from sticking to the cutter and keeps the cutter sharp if you se-
lect it when using adhesive paper.
G Mirror
Specify whether to print a mirror image, as needed. Select this option to print a version of the document or image with
the left and right sides inverted.
View Settings Dialog Box for the Printing Application
View Settings Dialog Box for the Printing Application
In the View Settings dialog box, you can check details of the selected printing application.
Note
• To display the View Settings dialog box, on the Main sheet, click View Settings by Print Target. (See "Main
Sheet .") ➔P.167
• A
Print Target
Shows all Print Target options (settings items for the printing application).
• B
Name
Identifies the item selected in Print Target by its name and an icon.
• C
Details
Here, you can confirm detailed settings values for each listed item for the selected Print Target.
Color Adjustment Sheet: Color
Color Adjustment Sheet: Color
If the color tone as printed is not as you expected, you can adjust it on the Color Adjustment sheet.
View Settings Dialog Box for the Printing Application
iPF680
User's Guide
Windows Software Printer Driver
172

Canon imagePROGRAF iPF680 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Page description languages	GARO, HP-GL/2, HP-RTL
Media thickness	0.07 - 0.8 mm
Maximum print size	-
Maximum roll length	18 m
Media width (rolls)	254 - 609.6 mm
Media width (sheets)	203.2 - 609.6 mm
Maximum roll diameter	150 mm
Paper tray media types	Coated paper, Cut sheet, Plain paper, Roll
ISO A-series sizes (A0...A9)	A1, A2, A3
ISO B-series sizes (B0...B9)	B2, B4
Certification	RoHS
Product color	Black, Grey
Sound pressure level (printing)	47 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10/100/1000 Base-T/TX Mbit/s
Ethernet interface type	Gigabit Ethernet
Compliance industry standards	IEEE 802.3ab, IEEE 802.3u, IEEE 802.3
Power consumption (standby)	0.5 W
Power consumption (typical)	140 W
Storage temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	20 - 80 %
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	757 mm
Width	997 mm
Height	507 mm
