Canon imagePROGRAF iPF680 User Manual

• Color Adjustment / Gray Adjustment / Matching
You can set the color adjustment and matching.
• Color Adjustment ➔ P.305
• Matching ➔ P.307
Note
• Matching is not displayed if No color correction has been selected in Color Mode.
• Restore Defaults Button
Click the button to reset to the setting when starting Preview.
• Print Button
Click the button to begin printing.
•
Update Printer Info. Button
Click the button to acquire printer information.
Color Adjustment
Color Adjustment
You can set the color adjustment.
Adjusting Color
Normally colors should be adjusted in the software application, but if you see colors in the printout that do not match
colors on the screen, you can perform color adjustments.
1 Select Color on Color Mode in the Color Settings panel.
2
Select Color Adjustment.
iPF680
Color Adjustment
User's Guide
Mac OS Software Preview
305

Canon imagePROGRAF iPF680 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Page description languages	GARO, HP-GL/2, HP-RTL
Media thickness	0.07 - 0.8 mm
Maximum print size	-
Maximum roll length	18 m
Media width (rolls)	254 - 609.6 mm
Media width (sheets)	203.2 - 609.6 mm
Maximum roll diameter	150 mm
Paper tray media types	Coated paper, Cut sheet, Plain paper, Roll
ISO A-series sizes (A0...A9)	A1, A2, A3
ISO B-series sizes (B0...B9)	B2, B4
Certification	RoHS
Product color	Black, Grey
Sound pressure level (printing)	47 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10/100/1000 Base-T/TX Mbit/s
Ethernet interface type	Gigabit Ethernet
Compliance industry standards	IEEE 802.3ab, IEEE 802.3u, IEEE 802.3
Power consumption (standby)	0.5 W
Power consumption (typical)	140 W
Storage temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	20 - 80 %
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	757 mm
Width	997 mm
Height	507 mm
