Canon imagePROGRAF iPF680 User Manual

Menu Settings
Menu Settings
Menu items are as follows.
The printer menu is classified into regular menu items available when no print job is in progress and menu during print-
ing items only available while printing is in progress. see "Printer Menu Operations." ➔ P.446
Regular menu Menu during printing
Paper Menu Not displayed
Ink Menu The same Ink Menu as normal is displayed.
Job Menu The same Job Menu as normal is displayed.
Set./Adj. Menu A limited Set./Adj. Menu containing the following items is displayed.
• Adj. Fine Feed (*1)
• Printer Info
*1: Only displayed in the menu during printing. Not displayed in the regular menu.
For instructions on selecting menu items, see "Menu Operations." ➔ P.447
For details on the displayed menu hierarchy, see "Menu Structure." ➔P.450
Paper Menu
The Paper Menu is not displayed during printing.
Setting Item Description, Instructions
Load Paper Select either sheets or rolls and load the paper.
Eject Paper Choose this item before removing loaded paper.
Chg. Paper Type (*1) Change the type of paper loaded. (See "Changing the Type of Pa-
per.") ➔P.376
Chg. Paper Size Change the size of paper loaded. (See "Specifying the Paper
Length.") ➔P.378 (See "Paper Sizes.") ➔ P.360
ManageRemainRoll Choose On to print a barcode at the end of a roll before you remove
it. The printed barcode can be used in managing the amount of roll
paper left. Choose Off if you prefer not to print the barcode.
(See "Keeping Track of the Amount of Roll Paper Left.") ➔ P.383
Paper Details (The type of paper
is displayed here.)
(*1)
Head Height Adjust the Printhead height. (See "Troubleshooting Paper Abrasion
and Blurry Images.") ➔P.530
Skew Check Lv. If you print on Japanese paper (washi) or other handmade paper
that has an irregular width, choose Loose for a higher skew detec-
tion threshold, or choose Off to disable skew detection. However, if
paper is loaded askew when detection is Off, note that paper jams
or Platen soiling may occur.
Cutting Mode Specify whether or not to cut with the standard round-bladed cutter.
If you choose Automatic, the roll will be cut automatically using the
Cutter Unit, depending on the printer driver settings.
Select Eject to prevent printed documents from falling immediately
after printing such as when you wait for the ink to dry, etc. Manual
prints lines at the cut position instead of cutting after printing.
(See "Specifying the Cutting Method for Rolls.") ➔ P.386
Cut Speed Choose the cutting speed. The preset selection represents the opti-
mal cutting speed for the type of paper. We recommend keeping the
preset cutting speed.
If you use adhesive paper, choosing Slow helps prevent adhesive
from sticking to the cutter and keeps the cutter sharp.
Trim Edge First Selects whether or not to automatically cut the leading edge of the
roll paper when roll paper is loaded.
Menu Settings iPF680
User's Guide
Control Panel Printer Menu
456

Canon imagePROGRAF iPF680 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Page description languages	GARO, HP-GL/2, HP-RTL
Media thickness	0.07 - 0.8 mm
Maximum print size	-
Maximum roll length	18 m
Media width (rolls)	254 - 609.6 mm
Media width (sheets)	203.2 - 609.6 mm
Maximum roll diameter	150 mm
Paper tray media types	Coated paper, Cut sheet, Plain paper, Roll
ISO A-series sizes (A0...A9)	A1, A2, A3
ISO B-series sizes (B0...B9)	B2, B4
Certification	RoHS
Product color	Black, Grey
Sound pressure level (printing)	47 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10/100/1000 Base-T/TX Mbit/s
Ethernet interface type	Gigabit Ethernet
Compliance industry standards	IEEE 802.3ab, IEEE 802.3u, IEEE 802.3
Power consumption (standby)	0.5 W
Power consumption (typical)	140 W
Storage temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	20 - 80 %
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	757 mm
Width	997 mm
Height	507 mm
