To view all the jobs in a set period, specify the period using Calculate Total for Period and then Starting Date (or
Starting Day of Week or Starting Month) in the View menu or the toolbar.
For example, to view monthly job logs starting on the 1st of each month, set Calculate Total for Period to Month-
ly and set Starting Date to 1.
Note
• Up to 10,000 regularly acquired jobs are displayed for each printer.
Exporting Print Job Data as a CSV File
Exporting Print Job Data as a CSV File
You can export the collected print job data in the form of a CSV file by selecting Export Job Cost Data in the File
menu.
Note
• You can also select Export Job Cost Data using the icon in the toolbar.
• Selected Jobs
Exports the data for the selected print jobs in the job list as a CSV file.
Note
• You can select multiple jobs by holding down the Shift key or Ctrl key as you click the job names.
• Listed Jobs
Exports the data for the print jobs currently displayed in the list as a CSV file.
Displaying Job Properties or Period Properties
Displaying Job Properties or Period Properties
You can display the Job properties dialog box or Period Properties dialog box to check detailed cost information and
other items.
The Job properties dialog box displays detailed information about the selected job.
The Period Properties dialog box displays detailed information within the Regularly Acquired Jobs period.
•
Displaying the Job properties Dialog Box
Select a job from the job list, and then select Show Job Properties from Job properties in the File menu. You
can also select multiple jobs at once.
Note
• You can also display the dialog box by selecting a job, right-clicking it, and then selecting Show Job Properties,
or by using the icon in the toolbar.
• Displaying the Period Properties Dialog Box
Select a period from the Regularly Acquired Jobs list, and then select Show Period Properties from Job prop-
erties in the File menu. You can also select multiple periods at once.
Note
• You can also display the dialog box by selecting and right-clicking a period and then selecting Show Period
Properties, or by using the icon in the toolbar.
iPF680
Exporting Print Job Data as a CSV File
User's Guide
Print Job Management Accounting (Windows)
519

Canon imagePROGRAF iPF680 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Page description languages	GARO, HP-GL/2, HP-RTL
Media thickness	0.07 - 0.8 mm
Maximum print size	-
Maximum roll length	18 m
Media width (rolls)	254 - 609.6 mm
Media width (sheets)	203.2 - 609.6 mm
Maximum roll diameter	150 mm
Paper tray media types	Coated paper, Cut sheet, Plain paper, Roll
ISO A-series sizes (A0...A9)	A1, A2, A3
ISO B-series sizes (B0...B9)	B2, B4
Certification	RoHS
Product color	Black, Grey
Sound pressure level (printing)	47 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10/100/1000 Base-T/TX Mbit/s
Ethernet interface type	Gigabit Ethernet
Compliance industry standards	IEEE 802.3ab, IEEE 802.3u, IEEE 802.3
Power consumption (standby)	0.5 W
Power consumption (typical)	140 W
Storage temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	20 - 80 %
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	757 mm
Width	997 mm
Height	507 mm
