Canon imagePROGRAF iPF680 User Manual

Cause Corrective Action
The loaded paper is too small. (See "Removing the Roll from the Printer.") ➔ P.378
(See "Removing the Roll Holder from Rolls.") ➔ P.381
2. Replace the roll with a roll 10 inches wide or larger.
(See "Attaching the Roll Holder to Rolls.") ➔ P.370
(See "Loading Rolls in the Printer.") ➔ P.373
The printer will resume printing.
Press ▲ or ▼ to select Stop Printing, and then press the OK button.
"Remove paper and check pap. size"
Cause Corrective Action
A sheet has come out of the printer during printing.
1. Press the Release Lever back and remove the paper.
2. Reload the sheet, aligning it with the guide on the right.
3. Pull the Release Lever forward.
4. If "Not finished printing. Finish printing remaining jobs?" is shown on the
Display Screen, press the OK button.
Printing will resume, starting from the page on which the error occurred.
(See "Loading Sheets in the Printer.") ➔ P.392
PaprWidth Mismatch
PaprWidth Mismatch
Cause Corrective Action
When Detect Mismatch in the Control Panel menu is
set to Pause, the width of the loaded roll does not
match the width specified in Fit Roll Paper Width in
the printer driver.
Press ▲ or ▼ to select Print, and then press the OK button to resume print-
ing.
However, note that this error may cause paper jams and affect the printing
quality.
Press ▲ or ▼ to select Stop Printing, and then press the OK button.
Follow these steps to replace the roll to match the width specified in the printer
driver.
1.
Press ▲ or ▼ to select Change Paper, and then press the OK button.
(See "Removing the Roll from the Printer.") ➔P.378
(See "Removing the Roll Holder from Rolls.") ➔ P.381
2. Replace with paper of the width configured in the printer driver.
(See "Attaching the Roll Holder to Rolls.") ➔ P.370
(See "Loading Rolls in the Printer.") ➔ P.373
The printer now starts printing the print job.
Make sure the roll width selected in the dialog box displayed when you select
Fit Roll Paper Width in the printer driver matches the width of the roll loaded
in the printer, and then try printing again.
Paper size not detected.
Paper size not detected.
Cause Corrective Action
Paper has been loaded
askew, or warped paper
has been loaded.
Follow these steps to reload the roll.
1. Press the OK button and reload the paper.
(See "Loading Rolls in the Printer.") ➔ P.373
2. Pull the Release Lever forward.
PaprWidth Mismatch iPF680
User's Guide
Error Message Messages regarding paper
612

Canon imagePROGRAF iPF680 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Page description languages	GARO, HP-GL/2, HP-RTL
Media thickness	0.07 - 0.8 mm
Maximum print size	-
Maximum roll length	18 m
Media width (rolls)	254 - 609.6 mm
Media width (sheets)	203.2 - 609.6 mm
Maximum roll diameter	150 mm
Paper tray media types	Coated paper, Cut sheet, Plain paper, Roll
ISO A-series sizes (A0...A9)	A1, A2, A3
ISO B-series sizes (B0...B9)	B2, B4
Certification	RoHS
Product color	Black, Grey
Sound pressure level (printing)	47 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10/100/1000 Base-T/TX Mbit/s
Ethernet interface type	Gigabit Ethernet
Compliance industry standards	IEEE 802.3ab, IEEE 802.3u, IEEE 802.3
Power consumption (standby)	0.5 W
Power consumption (typical)	140 W
Storage temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	20 - 80 %
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	757 mm
Width	997 mm
Height	507 mm
