Canon imagePROGRAF iPF680 User Manual

2
Select Rotate Left 90 Degrees orRotate Right 90 De-
grees from the toolbar.
Alternatively, you may click on the Rotate check box in
the Format Dialog Box ➔ P.207 then select Rotate
Right or Rotate Left, and click the OK button.
Laying out Objects Automatically
Laying out Objects Automatically
Click Auto Arrange Object in the tool bar. This automatically lays out objects. Alternatively, you may select Auto Ar-
range Object from the Object menu.
Note
• The object layout order varies depending on the Order setting in the Page Options Dialog Box ➔ P.206 dialog box.
Aligning Objects
Aligning Objects
You can align objects systematically.
1 Select multiple objects.
2 Click the align button from the toolbar.
Alternatively, you may select the align menu from the Object menu.
•
Align Top
Lays out the objects, justifying them to the top.
Laying out Objects Automatically iPF680
User's Guide
Windows Software Free Layout
216

Canon imagePROGRAF iPF680 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Page description languages	GARO, HP-GL/2, HP-RTL
Media thickness	0.07 - 0.8 mm
Maximum print size	-
Maximum roll length	18 m
Media width (rolls)	254 - 609.6 mm
Media width (sheets)	203.2 - 609.6 mm
Maximum roll diameter	150 mm
Paper tray media types	Coated paper, Cut sheet, Plain paper, Roll
ISO A-series sizes (A0...A9)	A1, A2, A3
ISO B-series sizes (B0...B9)	B2, B4
Certification	RoHS
Product color	Black, Grey
Sound pressure level (printing)	47 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10/100/1000 Base-T/TX Mbit/s
Ethernet interface type	Gigabit Ethernet
Compliance industry standards	IEEE 802.3ab, IEEE 802.3u, IEEE 802.3
Power consumption (standby)	0.5 W
Power consumption (typical)	140 W
Storage temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	20 - 80 %
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	757 mm
Width	997 mm
Height	507 mm
