Color Settings Pane: Color
Color Settings Pane: Color
In general, make any needed adjustments to the color of documents in the application used to create them. However, if
the color tone as printed is not as you expected, you can also adjust the color in the printer driver.
If the color tone as printed is not as you expected, you can adjust it on the Color Adjustment pane.
Note
• To display the Color Adjustment pane, on the Main pane click Color Settings by Color Mode in Advanced Settings.
(See "Main Pane .") ➔P.281
• For details on settings items, see "Adjusting the Color in the Printer Driver." ➔ P.51
• A Sample Type
Choose a sample image from Standard, Portrait, Landscape, or Graphics.
• B View Color Pattern
Select this checkbox to display the color pattern.
• C Apply to Sample
Select this checkbox to apply the changed settings to the sample image.
• D Cyan/ E Magenta/ F Yellow
Correct color tones by adjusting the levels of each color.
• G Gray Tone
Adjust the color tone of grays as desired. Choose Cool (tinged with blue) or Warm (tinged with red).
• H Brightness
Adjust the overall image brightness as desired. You can adjust the brightness if the printed document is lighter or
darker than the original image (that is, the original photo that was scanned or the original graphic as it appears on
the computer screen).
• I
Contrast
Adjust the contrast of the darkest and lightest portions relative to each other, as desired. Increasing the Contrast
makes images sharper, and reducing the Contrast softens images.
•
J
Saturation
Adjust the color intensity as desired. Increasing the Saturation setting makes colors more vivid, and reducing the
Saturation makes colors more subdued.
• K
Object Adjustment
Select this option to display the Object Adjustment dialog box, in which you can specify objects subject to color
adjustment.
iPF680
Color Settings Pane: Color
User's Guide
Mac OS Software Printer Driver
289

Canon imagePROGRAF iPF680 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Page description languages	GARO, HP-GL/2, HP-RTL
Media thickness	0.07 - 0.8 mm
Maximum print size	-
Maximum roll length	18 m
Media width (rolls)	254 - 609.6 mm
Media width (sheets)	203.2 - 609.6 mm
Maximum roll diameter	150 mm
Paper tray media types	Coated paper, Cut sheet, Plain paper, Roll
ISO A-series sizes (A0...A9)	A1, A2, A3
ISO B-series sizes (B0...B9)	B2, B4
Certification	RoHS
Product color	Black, Grey
Sound pressure level (printing)	47 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10/100/1000 Base-T/TX Mbit/s
Ethernet interface type	Gigabit Ethernet
Compliance industry standards	IEEE 802.3ab, IEEE 802.3u, IEEE 802.3
Power consumption (standby)	0.5 W
Power consumption (typical)	140 W
Storage temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	20 - 80 %
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	757 mm
Width	997 mm
Height	507 mm
