Canon imagePROGRAF iPF680 User Manual

Cause Corrective Action
A print job for printing on sheets
was sent when a roll is loaded.
Press ▲ or ▼ to select Stop Printing, and then press the OK button to stop printing.
Paper jam
Paper jam
Cause Corrective Action
A paper jam oc-
curred in the
printer during
printing.
For roll paper, cut the paper on the upper side of the {Paper Feed Slot.
1. Push the Release Lever back and remove the jammed paper.
(See "Clearing Jammed Roll Paper.") ➔ P.579
(See "Clearing a Jammed Sheet.") ➔ P.582
2. Load the paper.
(See "Loading Rolls in the Printer.") ➔ P.373
(See "Loading Sheets in the Printer.") ➔ P.392
3. Pull the Release Lever forward.
4. If "Not finished printing. Finish printing remaining jobs?" is shown on the Display Screen, press the OK but-
ton.
Printing will resume, starting from the page on which the error occurred.
Paper is crooked.
Paper is crooked.
Cause Corrective Action
Paper loaded crooked was detected when the paper was advanced. Follow these steps to reload the roll.
1. Push the Release Lever back.
2. Adjust the right edge of the roll to make it parallel to the orange
Paper Alignment Line.
3. Pull the Release Lever forward.
(See "Loading Rolls in the Printer.") ➔ P.373
If this error recurs after you reload the roll, remove the Roll Holder
from the printer, push the roll firmly in until it touches the Roll
Holder flange, and reload the Roll Holder in the printer.
(See "Attaching the Roll Holder to Rolls.") ➔ P.370
Follow these step to reload a sheet.
1. Push the Release Lever back.
2. Pull out the sheet.
3. Pull the Release Lever forward.
4. Reload the sheet, aligning it with the guide on the right.
(See "Loading Sheets in the Printer.") ➔ P.392
Important
• To disable this message (if it is displayed repeatedly despite reloading paper, for example), choose Off or Loose in
the Skew Check Lv. setting of the printer menu. However, this may cause jams and printing problems because paper
may be askew when printed. Also, the Platen may become soiled, which may soil the back of the next document
when it is printed.
iPF680 Paper jam
User's Guide
Error Message Messages regarding paper
615

Canon imagePROGRAF iPF680 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Page description languages	GARO, HP-GL/2, HP-RTL
Media thickness	0.07 - 0.8 mm
Maximum print size	-
Maximum roll length	18 m
Media width (rolls)	254 - 609.6 mm
Media width (sheets)	203.2 - 609.6 mm
Maximum roll diameter	150 mm
Paper tray media types	Coated paper, Cut sheet, Plain paper, Roll
ISO A-series sizes (A0...A9)	A1, A2, A3
ISO B-series sizes (B0...B9)	B2, B4
Certification	RoHS
Product color	Black, Grey
Sound pressure level (printing)	47 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10/100/1000 Base-T/TX Mbit/s
Ethernet interface type	Gigabit Ethernet
Compliance industry standards	IEEE 802.3ab, IEEE 802.3u, IEEE 802.3
Power consumption (standby)	0.5 W
Power consumption (typical)	140 W
Storage temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	20 - 80 %
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	757 mm
Width	997 mm
Height	507 mm
