Canon imagePROGRAF iPF680 User Manual

2
On the Output Settings Panel ➔ P.302 , click the No
Spaces at Top or Bottom check box on.
3
Click the Print button.
Printing on the settings with no spaces at top or bottom begins.
Print Page Rotated 90 Degrees
Print Page Rotated 90 Degrees
You can save paper by printing in landscape orientation on roll paper.
1 On the Paper Settings Panel ➔ P.298 , select Roll Paper in Paper Source.
2 On the Output Settings Panel ➔ P.302 , click the Rotate Page check box on.
3
Select Rotate Right 90 Degrees or Rotate Left 90 De-
grees.
4
Click the Print button.
Printing on rotating 90 degrees begins.
Display with Fitting to the Width of the Paper
Display with Fitting to the Width of the Paper
In the preview area, you can display to the width of the paper.
1
Select Fit to Width from the tool bar.
Print Page Rotated 90 Degrees iPF680
User's Guide
Mac OS Software Preview
314

Canon imagePROGRAF iPF680 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Page description languages	GARO, HP-GL/2, HP-RTL
Media thickness	0.07 - 0.8 mm
Maximum print size	-
Maximum roll length	18 m
Media width (rolls)	254 - 609.6 mm
Media width (sheets)	203.2 - 609.6 mm
Maximum roll diameter	150 mm
Paper tray media types	Coated paper, Cut sheet, Plain paper, Roll
ISO A-series sizes (A0...A9)	A1, A2, A3
ISO B-series sizes (B0...B9)	B2, B4
Certification	RoHS
Product color	Black, Grey
Sound pressure level (printing)	47 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10/100/1000 Base-T/TX Mbit/s
Ethernet interface type	Gigabit Ethernet
Compliance industry standards	IEEE 802.3ab, IEEE 802.3u, IEEE 802.3
Power consumption (standby)	0.5 W
Power consumption (typical)	140 W
Storage temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	20 - 80 %
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	757 mm
Width	997 mm
Height	507 mm
