Canon imagePROGRAF iPF680 User Manual

• I Thicken Fine Lines
Select this option to print fine lines more distinctly.
• J Unidirectional Printing
Select this checkbox to prevent problems such as misaligned lines and improve the print quality. However, the
printing speed becomes slower.
• K Sharpen Text
Select this option to print text more sharply.
Paper Information on Printer Dialog Box
Paper Information on Printer Dialog Box
On the Paper Information on Printer dialog box, you can obtain information on the paper in the printer and configure
printer driver settings for the paper source and media type.
Note
• To display the Paper Information on Printer dialog box, on the Main sheet, click Get Information by Media Type.
(See "Main Sheet .") ➔P.167
•
A Paper Source
Shows the paper source supported by the printer, as well as information about the loaded paper. To update the
paper source and media type settings in the printer driver, select the desired Paper Source option and click OK.
Paper Detailed Settings Dialog Box
Paper Detailed Settings Dialog Box
In the Paper Detailed Settings dialog box, you can set Drying Time for the paper selected with Media Type of the
Main sheet, etc.
You can display this dialog box by clicking Advanced Settings of Media Type on the Main sheet. (See "Main
Sheet .") ➔ P.167
Paper Information on Printer Dialog Box
iPF680
User's Guide
Windows Software Printer Driver
170

Canon imagePROGRAF iPF680 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Page description languages	GARO, HP-GL/2, HP-RTL
Media thickness	0.07 - 0.8 mm
Maximum print size	-
Maximum roll length	18 m
Media width (rolls)	254 - 609.6 mm
Media width (sheets)	203.2 - 609.6 mm
Maximum roll diameter	150 mm
Paper tray media types	Coated paper, Cut sheet, Plain paper, Roll
ISO A-series sizes (A0...A9)	A1, A2, A3
ISO B-series sizes (B0...B9)	B2, B4
Certification	RoHS
Product color	Black, Grey
Sound pressure level (printing)	47 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10/100/1000 Base-T/TX Mbit/s
Ethernet interface type	Gigabit Ethernet
Compliance industry standards	IEEE 802.3ab, IEEE 802.3u, IEEE 802.3
Power consumption (standby)	0.5 W
Power consumption (typical)	140 W
Storage temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	20 - 80 %
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	757 mm
Width	997 mm
Height	507 mm
