Canon imagePROGRAF iPF680 User Manual

Cause Corrective Action
The Printhead cannot be recognized because it is not installed correctly.
1. Open the Top Cover.
2. Reinstall the Printhead.
(See "Replacing the Printhead.") ➔ P.551
Execute printhead cleaning.
Execute printhead cleaning.
Cause Corrective Action
The Printhead noz-
zles are clogged.
Follow these steps to clean the Printhead.
1. Stop printing by pressing ▲ or ▼ to select Stop Printing.
2. Clean the Printhead.
(See "Cleaning the Printhead.") ➔ P.550
If the message is still displayed when printing, replace the Printhead.
(See "Replacing the Printhead.") ➔ P.551
Press ▲ or ▼ to select Print, and then press the OK button to resume printing. However, note that this error may
affect the printing quality.
iPF680 Execute printhead cleaning.
User's Guide
Error Message Messages regarding printheads
623

Canon imagePROGRAF iPF680 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Page description languages	GARO, HP-GL/2, HP-RTL
Media thickness	0.07 - 0.8 mm
Maximum print size	-
Maximum roll length	18 m
Media width (rolls)	254 - 609.6 mm
Media width (sheets)	203.2 - 609.6 mm
Maximum roll diameter	150 mm
Paper tray media types	Coated paper, Cut sheet, Plain paper, Roll
ISO A-series sizes (A0...A9)	A1, A2, A3
ISO B-series sizes (B0...B9)	B2, B4
Certification	RoHS
Product color	Black, Grey
Sound pressure level (printing)	47 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10/100/1000 Base-T/TX Mbit/s
Ethernet interface type	Gigabit Ethernet
Compliance industry standards	IEEE 802.3ab, IEEE 802.3u, IEEE 802.3
Power consumption (standby)	0.5 W
Power consumption (typical)	140 W
Storage temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	20 - 80 %
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	757 mm
Width	997 mm
Height	507 mm
