Note
• If the Tab Selection screen is not displayed, press the Menu button.
2 Press the OK button.
The Set./Adj. Menu is displayed.
3 Press ▲ or ▼ to select Interface Setup, and then press the OK button.
4 Press ▲ or ▼ to select TCP/IP, and then press the OK button.
5
Press ▲ or ▼ to select IPv4, and then press the OK button.
6
Press ▲ or ▼ to select IPv4 Settings, and then press the OK button.
7
Press ▲ or ▼ to select IP Address, and then press the OK button.
8
After you press ◀ or ▶ to select the input field, numerical input is possible.
9
Press the ▲ or ▼ button to enter the value.
Note
• Pressing the ▲ button increases the number by 1. The maximum value is 9, after which 0 is displayed.
• Pressing the ▼ button decreases the number by 1. The minimum value is 0, after which 9 is displayed.
• Hold down ▲ or ▼ to increase or decrease the value continuously.
• Make sure the IP address you enter for the printer is not the same as any computer IP address in your net-
work.
10 Repeat steps 8 and 9 to complete the settings, and then press the OK button.
11
Press the Menu button.
If you have changed the settings, a confirmation message is dis-
played. Press ▲ or ▼ to select Yes, and then press the OK button.
Important
• Be sure to complete step 11. This will activate the values you have entered.
• If an error message is displayed, check the settings and correct any invalid values.
Note
• You can also specify the subnet mask and default gateway on the Control Panel.
Configuring the IP Address Using ARP and PING Commands
Configuring the IP Address Using ARP and PING Commands
This topic describes how to configure the IP address using ARP and PING commands.
iPF680 Conguring the IP Address Using ARP and PING Commands
User's Guide
Network Setting Initial Settings
489

Canon imagePROGRAF iPF680 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Page description languages	GARO, HP-GL/2, HP-RTL
Media thickness	0.07 - 0.8 mm
Maximum print size	-
Maximum roll length	18 m
Media width (rolls)	254 - 609.6 mm
Media width (sheets)	203.2 - 609.6 mm
Maximum roll diameter	150 mm
Paper tray media types	Coated paper, Cut sheet, Plain paper, Roll
ISO A-series sizes (A0...A9)	A1, A2, A3
ISO B-series sizes (B0...B9)	B2, B4
Certification	RoHS
Product color	Black, Grey
Sound pressure level (printing)	47 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10/100/1000 Base-T/TX Mbit/s
Ethernet interface type	Gigabit Ethernet
Compliance industry standards	IEEE 802.3ab, IEEE 802.3u, IEEE 802.3
Power consumption (standby)	0.5 W
Power consumption (typical)	140 W
Storage temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	20 - 80 %
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	757 mm
Width	997 mm
Height	507 mm
